4.3 Parameter (Transparent UDP Mode)
Function UDP-Port
Control Port
3497
Data Port
3498
.6
ipEther232
Version 11
Command Answer Description
“open” ve “ok” or “error” Opens the Connection or keep it ali
“openex” Opens the Connection exclusively or
keep it alive
“ok” or “error”
“open password” “ok” or “error” Like “open” but with Password
“openex password” “ok” or “error” Like “openex” but with Password
“close“ “ok” or “error” Closes the Connection
“mode” “mode 9600,8,n,1” Get the current UART Mode
“mode 9600,8,n,1” “ok” or “error” Sets the UART Mode
“tc57” “tc57 mode,fl,hl Get the current TC57 Mode. See
ipEther-Docu
“tc57 no” “ok” or “error” Disables the TC57
“tc57 1.1” “ok” or “error” Sets the TC57 Mode to Format 1.1
“tc57 1.2, fl” “ok” or “error” Sets the TC57 Mode to Format 1.2
“tc57 2, fl,hl” “ok” or “error” Sets the TC57 Mode to Format 2
“tc57 3, fl,hl” “ok” or “error” Sets the TC57 Mode to Format 3
“rxdtimeout”
“rxdtimeout 100”
Get the current RXD-Timeout. See
ipEther-Docu
“rxdtimeout 100” “ok” or “error” Sets the RXDTimeout.
“chartimeout”
“chartimeout 100”
Get the current Character Distance.
See ipEther-Docu
“chartimeout 100” “ok” or “error” Sets the Character Distance.
“nomodemsignals 1” “ok” or “error” 1=Ignores the Modemsignals, 0=Uses
the Modem
Mode: Baudrate,DataBits,Parity,StopBits
Baudrate: 2400, 4800, 9600, 19200, 38400, 57600, 115200
DataBits: 7, 8
Parity: n, e, o, 1, 0 (= None, Even, Odd, Mark, Space)
StopBits: 0, 1, 2
TC57: Mode to Format, Length of the Fixed Frame, Length of Header
The Frame Format FT 1.2, FT 2 and FT 3 have a Frame with fixed length.
The transmission frame formats - FT 1.2, FT 2 and FT 3 have a Frame of fixed
length.
The Frame with variable length for FT 2 and FT 3 have a header of fixed length.
It includes “Start character”, “Length” byte, “User Data” and “Check sequence”.
The user must select the desired Format and include values for “Fixed frame
length” and “Header length” parameters.
Mode: Frame-Format - 1.1, 1.2, 2, 3
Fl: Length of the Fixed Frame - Bereich 2 … 255 bytes
Hl: Length of Header - Bereich 2 … 14 bytes
See IEC 60870-5-1 IEC 60870-5-2
Änderungen vorbehalten Stand 09.09.05
ipcas GmbH ipEther232 V11.01 Seite 40 von 150
