6.10 Overvie
ters, enabling you to modify its configuration (see
lso ATS command).
w of the registers
The modem has internal regis
a
Register Definition Default Options
S0 Auto answer 0 [0..9] rings
S1 Number of rings 0 Read only
S2 Escape Character + ASCII
S3 CR-Character 0x0d ASCII
S LF-Char ASCII 4 acter 0x0a
S5 BS-Character 0x08 ASCII
S30 Inactive-Timer 0 [0..255] ms
S31 Baud rate 3 1=2400 2=4800 3=9600 4=19200
5=38400 6=57600 7=115200
S32 Parity 0 0=None 1=Even 2=Odd 3=Mark
4=Space
S33 DataBits 8 7=7 8=8
S34 StopBits 1 1=1 2=2
S35 Rxd-Timeout 100 [5..255] ms
S36 Char-Timeout 10 [5..255] ms 0=Off
S37 Bit options 5 [0..255] decimal value
S38 Use TC57 0 [0..1]
S39 TC57 type 1 [0..3]
S40 fixed frame length 2 [2..255]
S41 User data length 2 [2..14]
S81 Password protection 0 [0..1]
S82 Password blocking time 3 [0..255] minutes 0=Off
S83 Wrong password entry 0 [0..255] in the RAM only
S99 * Time between two rings 4 [0..255] s
S100 Own IP 10.10.5.1 xxx.xxx.xxx.xxx
S101 DefaultGateway 0.0.0.0 xxx.xxx.xxx.xxx
S102 AutoRemote 0.0.0.0 xxx.xxx.xxx.xxx
S103 SubnetMask 255.255.255.0 xxx.xxx.xxx.xxx
S104 MAC address 00:09:8E:x:x:x Read only
S110 * Valid IP address 0.0.0.0 xxx.xxx.xxx.xxx
S111 * V xxx.xxx.xxx.xxx alid IP address 0.0.0.0
S112 * Valid IP address 0.0.0.0 xxx.xxx.xxx.xxx
S113 * Valid I xx P address 0.0.0.0 xxx.xxx.xxx.x
S114 * Valid I .xxx P address 0.0.0.0 xxx.xxx.xxx
S115 * Valid I .0 xx.xxx.xxx P address 0.0.0 xxx.x
S116 * Valid IP address 0.0.0.0 xxx.xxx.xxx.xxx
S117 * Valid I P address 0.0.0.0 xxx.xxx.xxx.xxx
S118 * Valid IP address 0.0.0.0 xxx.xxx.xxx.xxx
S119 * Valid IP address 0.0.0.0 xxx.xxx.xxx.xxx
* Regis
ters are not issued with AT&V
Änderungen vorbehalten Stand 09.09.05
ipcas GmbH ipEther232 V11.01 Seite 71 von 150
