IpCAS ipEther232 - ipNTP Technical Details

8.5 Technical details for ipNTP
Great emphasis was placed on compatability during device design. Nevertheless
there are some minor restrictions.
• The DCF77-Reception has a accuracy of ± 8 msec.
• The GPS-Reception has a accuracy of ± 1 msec.
• Free running quality: ± 10 ppm at a static temperature of +10°C to
+ 50°C.
• The emergency clock has an accuracy of 50ppm by a temperature
(+10°C to +50°C).
Technische Details DCF77-Antenne
Technical characteristics Min. Typical Max. Unit
Receive frequenz 77,5 kHz
Connection cable length 2,5 m
Power supply 3 12 V
Power supply range 2,2 15 V
Reception sensivity 30 50 µV/m
Output voltage 3 30 V
Output current 2 mA
Output level at 100% 77,5kHz 0,4 V
Output level at 25% 77,5kHz Uoutput V
Output impulse range at
Transmit impulse range: 100ms
200ms
80
170
130
230
ms
ms
Power consumption 1,3 mA
Bandwith of the filter 350 Hz
Attenuation at ± 3 x BW -20 dB
Store temperature -40 80 °C
Operating temperature 0 50 °C
Technische Details GPS-Antenne
Power supply 4.0V bis 5,5V
signal level; supply voltage 60 mA bei 5V
output level 0V bis VEingang
GPS receiver sensitivity
mind. 165 dBW
Correction data
WAAS / EGNOS
Data format version
NMEA 0183 v2.00 oder v3.00
Time impulse
update rate
1pps, +/- 1µsec
1 Synchronisation pro Sekunde
Synchronization time
Neusynchronisation: < 2 sec
Warm: ca. 15 sec
Kalt: ca. 45 sec
Auto Locate™: 5 min
Sky Search: 5 min
Weight without cables
115,6g
Weatherproof case
Polykarbonat Thermoplastik,
Wasserfest nach IEC 60529
Work temperature range
- 30°C bis + 80°C
Storage temperature range - 40°C bis + 90°C
Measurements in mm
19,5 x 61
Cable length
3 Meter
Änderungen vorbehalten Stand 09.09.05
ipcas GmbH ipEther232 V11.01 Seite 107 von 150
