IpCAS ipEther232 - Page 129

Software Interfaces
Windows.Forms Control •
• OCX/ActiveX Control for the adoption in..
-Code in Microsoft .Net
transparence access on the RS232 with
- Windows.Forms Control
- OCX/ActiveX Control
Further Technical Details
- own developement
- Office Application
• OPC DA 2.0 / 3.0 in future
• Delivery inclusive dokumented Source
• MSDN compatible help-Files
• dokumented Ethernet Interface
•
ipEther232.IO OEM Version desktop DIN-Rail Unit
 1 x RS232 SUB-D9 (RX / TX / GND)
 6 x 24V DC input channels
 Isolation Voltage : 1,5 KV
 channel separation: 500 V
 inputscancyclic: 1 ... 255 ms
 input debounce: 1 ... 15 fold Scancyclic
Interfaces
1 x 10BaseT – RJ45 (can be operated in networks with 10/100 MBit/s)
Diagnosis-LEDs
Power, System, Error,
RS232 Send/Receive
Ethernet Send/Receive/Link
Supply voltage
+ 8 - 14 V DC – input jack
5 V DC pin row on plate
+ 8 - 14 V DC - input jack
+ 8 - 14 or 24 V DC
1)
input jack and
3,5mm connector
Housing without housing Plastic housing Plastic housing
Dimensions W/H/D approx. 100/20/70 mm approx. 45/108/73 mm approx. 45/108/73 mm
Operating/Storage temperature 5° C to 55° C / -10° C to 70° C
Relative humidity 5 % to 90 % non-condensing
Standards CE
ipEther232.IO
Without power supply
wall power supply
2)
input: 230 V AC
output: + 9 V DC
Without power supply
(Optionally)
configurationssoftware
drivers for Windows (NT, 2000, XP)
Scope of delivery
userguide (english or german)
Order number RS232 0202023-OEM 0202023
0202023-H
0202023-H24
0202023-H60
1)
Further voltages on request
2)
Delivery only at countries with 230 V AC 50Hz
Änderungen vorbehalten Stand 09.09.05
ipcas GmbH ipEther232 V11.01 Seite 129 von 150
