J1: LAN-Interface
1 TX+ 3 RX+
2 TX- 6 RX-
J4: RS232- / RS485-Interface
1 CD / - 6 DSR / RX+
2 RXD / TX+ 7 RTS / RX-
3 TXD / TX- 8 CTS / -
4 DTR / - 9 RI / -
5 GND/GND
J6: LAN-Interface (OEM)
1 TX+ 3 RX+
2 TX- 4 RX-
J7: LED-Interface (OEM)
1 +5V 6 LED_LAN_RXD
2 LED_POWER 7 LED_LAN_TXD
3 LED_SYSTEM 8 LED_SYSTEM2
4 LED_COM_TXD 9 LED_LAN_LINK
5 LED_COM_RXD 10 GND
J8: Modul-Interface (RS232 / RS485 | SNTP)
1 CD 6 RTS / RX- Antenna
2 DSR / RX+ 7 TXD / TX-
3 RXD / TX+ 8 DTR
4 CTS 9 DTR_TTL Antenna Loopback
5 RI VCC Antenna
J9: Modul-Interface (RS232 / RS485 | SNTP)
1 +5V +5V 6 CTS_TTL
2 GND GND 7 RI_TTL
3 CD_TTL SCL 8 RTS_TTL Antenne
4 DSR_TTL SDA 9 TXD_TTL
5 RXD_TTL
J10: RS232- / RS485-Interface (OEM)
1 CD / - 6 CTS / -
2 DSR / RX+ 7 DTR / -
3 RXD / TX+ 8 RI / -
4 RTS / RX- 9 GND
5 TXD / TX- 10 n/c
JP6: Supply votage input(OEM)
1 GND 2 Vin+ (8 – 14 VDC)
JP7: 5V Supply voltage input (OEM)
1 GND 2 +5V
