“remoteip 0.0.0.0”
“remoteport 57138”
“gwsource 0”
Get the current Remote IP (GW Mod
Get the current Remote Po
Get the curre
“gwidleto 120”
e).
rt(GWMode).
nt QW Source (GWMode).
Get the current QW Idle Timeout (GW Mode).
“mode 9600,8,n,1” “ok” or “error” Sets the UART Mode
“tc57 no” “ok” or “error” Disables the TC57
“tc57 1.1” “ok” or “error” Sets the TC57 Mode to Format 1.1
“tc57 1.2, fl” “ok” or “error” Sets the TC57 Mode to Format 1.2
“tc57 2, fl,hl” “ok” or “error” Sets the TC57 Mode to Format 2
“tc57 3, fl,hl” “ok” or “error” Sets the TC57 Mode to Format 3
“rxdtimeout 200” “ok” or “error” Sets the RXDTimeout. (10, 20, …30000ms)
“chartimeout 0” “ok” or “error” Sets the Character Distance.(0, 10,…250ms)
“nomodemsignals ” “ok” or “error” 1=Ignores the Modem signals, 0=Uses the
Modem.
1
“rs485halfduplex 0“ “ok” or “error” 1=Full, 0=Half duplex mode.
“echo 1” “ok” or “error” 1=Echo enable, 0=Echo disable.
“subnetmask
255.255.255.0”
“ok” or “error” Sets the subnet mask.
“gateway 10.10.5.1” “ok” or “error” Sets the gateway.
“tcptimeout 1800” “ok” or “error” Set the time out for TCP connection.
(60…4294967294sec.)
“portdata 57137” “ok” or “error” Set the data port number. (0 … 65535)
“remoteip 0.0.0.0” “ok” or “error” Set the remote IP address.
0.0.0.0 - Telnet server mode.
x.x.x.x – Telnet client mode.
“remoteport 57138” “ok” or “error” Set the remote port number. (0 … 65535)
“gwsource 0” “ok” or “error” Sets the condition to open a TCP connection
in Gateway mode.
“gwidleto 120” “ok” or “error” Sets Time out. This parameter is active when
gwsource=0. (0… 65535sec.)
„T=3000 R=2FCC DSR=1
CTS=1 DCD=1 RI= “
--- Receives the ipEther.Telnet Status.
0
“uarterror 1” --- Receives the UART status.
“exit” --- Exit from Command Telnet Terminal.
Mode: audrate,DataBits,Parity,StopBits B
Baudrate: 400, 4800, 9600, 19200, 38400, 57600, 115200
ataBits: 7, 8
arity: n, e, o, 1, 0 (= None, Even, Odd, Mark, Space)
topBits: 0, 1, 2
C57: Mode to Format, Length of the Fixed Frame, Length of Header
2
D
P
S
T
The transmission frame formats - FT 1.2, FT 2 and FT 3 have a Frame of fixed
length.
The Frame with variable length for FT 2 and FT 3 have a header of fixed length. It
includes “Start character”, “Length” byte, “User Data” and “Check sequence”.
The user must select the desired Format and include values for “Fixed frame
length” and “Header length” parameters.
Fl: ch 2 … 255 bytes
Hl: ereich 2 … 14 bytes
Length of the Fixed Frame - Berei
Length of Header - B
Änderungen vorbehalten Stand 09.09.05
ipcas GmbH ipEther232 V11.01 Seite 48 von 150
