1 x RS232 or 1 x RS485 – SUB-D9 (Full RS232)
 Baudrate: 2.400 to 115.200 baud
 Parity: None, Even, Odd, Mark, Space
 Data: 8 Bits
 Stop: 1 or 2 Bits
Interfaces
1 x 10BaseT – RJ45 (may be operated in 10/100 MBit/s networks)
Diagnosis (LED)
Power, System, Error,
RS232 bzw. RS485 Send/Receive,
Ethernet Send/Receive/Link
Supply voltage
+ 8 - 14 V DC – Input Jack 5 V
DC on-board connector
+ 8 - 14 V DC – Input Jack
+ 8 - 14 or 24 V DC
1)
Input Jack and
3,5mm connector
Housing Without housing Plastic housing Plastic housing
Dimensions W/H/D Approx. 100/20/70 mm Approx. 110/30/75 mm Approx. 45/108/73 mm
Operating / storage temperature 5° C to 55° C / -10° C to 70° C
Relative humidity 5 % to 90 % non condensing
Standards CE
ipEther232.Telnet
Without power supply
External power supply input:²
)
230 V AC Output: 9 V DC
Without power supply
Configuration software
Driver for Windows (NT, 2000, XP)
Scope of delivery
Documentation (German or English)
Order number RS232 0202020
1)
Further voltages on request
2)
Only Delivery in countries with 230 V AC 50 Hz
