U RT
he UART supports transmission speeds between 2400 baud and 115200 baud.
ght result in data loss, if data is transmitted continuously.
Further techni
A
T
Higher baud rates mi
7 or 8 data bits can be used.
The parities "none", "even", "odd", "1" and "0" are supported.
7-bit data does not support the parity "none"..
cal details
IpEther232.Modem
OEM Version Desktop DIN-Rail Unit
1 x RS232 or 1 x RS485 – SUB-D9 (full RS232)
 Baud rate: 2.400 to 115.200 baud
 Parity: None, Even, Odd, Mark, Space
 Data: 7 or 8 Bits
 Stop: 1 or 2 Bits
Interfaces
1 x 10BaseT – RJ45 (may be operated in 10/100 MBit/s networks)
Diagnosis (LED)
Power, System, Error,
RS232 bzw. RS485 Transmit/Receive,
Ethernet Transmit/Receive/Link
Supply voltage
+ 8 - 14 V DC – Input Jack
5 V DC on board connector
+ 8 - 14 V DC – Input Jack
+ 8 - 14 oder 24 V DC
1)
Input Jack and
3,5mm connector
Housing Without housing Plastic housing Plastic housing
Dimensions W/H/D Approx. 100/20/70 mm Approx. 110/30/75 mm Approx. 45/108/73 mm
Operating / storage temperature 5° C to 55° C / -10° C to 70° C
Relative humidity 5 % to 90 % non-condensing
Standards CE
ipEther232.Modem
Without power supply
External power supply
Input: 230 V AC
Output: + 9 V DC
Without power supply
Configuration software
Driver for Windows (NT, 2000, XP)
Scope of delivery
Documentation (German or English)
RS232 0202014M-OEM 0202014M 0202014M-H
Bestellnummer
RS485 0202015M-OEM 0202015M 0202015M-H
1)
Further voltages on request
2)
Delivery only into countries with 230 V AC 50Hz
Änderungen vorbehalten Stand 09.09.05
