ISHIDA UNI-7 User Manual

PRECAUTIONS FOR SAFE USE

• Do not hold the operation panel or weigh platter
when carrying the machine.
Doing so may cause the operation panel or the platter to
break down.

• Do not hold the customer display for the pole type
when carrying the machine.
Dropping the machine may result in injury or cause the
machine to break down.
• Handle with care when removing or inserting the
cassette.
Careless cassette handling may result in injury or cause
the cassette to break down.
• Do not drop the cassette.
Dropping the cassette may result in injury or cause the
cassette to break down.
• Do not press the touch panel with an edged thing.
Doing so may scratch the panel and cause the machine
to break down.
• Risk of explosion if battery is replaced by an
incorrect type. Make sure to dispose of used
batteries according to the instructions.
UNI-7 User’s Manual iii

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
