Isoprime 100 - Tune File Management and Usage

Isoprime User’s Guide
Version 1.02 IsoPrime100 User’s Guide Page 76 of 219
9
Electron Voltage Short Circuit
Electron energy voltage < 10 V with > 5mA of emission. Filament to source
leakage or short circuit (only occurs when the filament is hot).
10
No Electron Voltage
Electron voltage < 10 V with < 5mA of emission. Electron voltage circuit
malfunction.
11
Electron Voltage Low
Electron voltage > 6 V below requested value. Electron voltage circuit
malfunction
12
Trap Leakage
Trap voltage < 17 V with trap current of at least
50µA in apparent regulation. Trap to source leakage current. Confirm by
requesting zero trap current and
monitor trap current.
13
High Trap Current
Trap current > 100 µA higher than requested value. Trap to source leakage
current. Confirm by requesting zero trap current and monitor trap current.
14
Filament Open Circuit
Low trap current with 0.12-0.45 A filament current reading. Open circuit
filament.
15
No Filament Current
Incorrect trap current with < 0.12 A filament current. Filament circuit
malfunction.
16
Low Filament Current
Low trap current with filament not in limit. Excessive resistance in filament
leads, poor filament or filament circuit malfunction.
17
Zero Trap Current
No trap current requested. Filament switches off.
18
Filament Limit
Low trap current with maximum filament current.
Poor or misaligned filament, open circuit trap lead,
electron voltage setting too low.
19
Low 22V
Supply voltage < 19 V. Power supply or circuit malfunction causing filament
circuit to switch off
20
High 22V
Supply voltage > 25 V. Circuit malfunction causing filament circuit to switch
off
255
Source Off
Source turned off
TUNE FILES
The current tune settings, source parameters and acquisition map may be saved in a tune file.
The name of the current file is displayed in the title bar. If changes have been made to the
