IsoPrime User’s Guide
Version 1.01 IsoPrime100 User’s Guide Page 97 of 219
 Resolution. The instrument resolution (M/M) at the peak centre of the centre
beam.
 Abundance Sensitivity. This is the contribution to the background by the tail
of the target beam peak at the peak centre of the centre beam.
This information is all stored in the current scan file. The software calculates the accelerating
voltage for the middle of the peak and displays the change in voltage that is necessary to update
the present value. To use the calculated value, click the Accept Peak Centre button.
The peak centre results window may be displayed at any time by choosing View, Peak Centre.
PEAK DISPLAY
The peak display window is used to view the results of the peak centre or other source scans.
To open the peak display page, either press the peak display toolbar button , or select View,
Peak Display. The peak display page is shown below:
