6-103
SERVICE AND MAINTENANCE
2
1
Lock button
Removal
Press the lock button and slide the wiper
blade in the direction of the arrow to
remove it from the wiper arm.
NOTE
• When the vehicle is driven with the
wiper in the service position, the
wiper is automatically switched from
the service position to the normal
position.
4. To switch the wiper to the normal
position, switch the power mode to
"ON" (models with passive entry and
start system) or turn the starter switch
to the "ON" position (models without
passive entry and start system), and
then place the wiper switch in any
position other than "OFF".
5108428_sec06_SERVICE AND MAINTENANCE_P001-140.indd 103 2020/11/05 11:54:19
