5.2.2 Battery Discharging Test Function

The IT6000B series power system provides the battery discharging test func-

tion, which is suitable for discharging tests on all types of portable batteries. The

user can set three cut off conditions: cut off voltage, current off capacity and the

charging time. If anyone of the three conditions are satisfied, the test will be in-

terrupted automatically.

BATTERY

Battery discharging test function

Run

Indicates that the battery test mode is entered and

waits to trigger the running of the currently edited bat-

tery test file.

Edit

Edit the battery discharging test file.

Cut Off Voltage Battery test cut-off voltage

Cut Off Capacity Battery test cut-off capacity

Cut Off Timer

Battery test cut-off time

The operation steps to set the battery discharging test function are as follows.

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob or Up/Down key to select BATTERY and press [Enter].

The interface is displayed as follows:

BATTERY TEST

Run Edit

3. Press the Left/Right key to select Edit and press [Enter].

4. Set the Cut Off Voltage, Cut Off Capacity and other parameters, and then

press [Enter] to confirm.

After the parameter setting is completed, the interface returns to the Battery

function main interface and displays as follows:

BATTERY TEST

Run Edit

5. Press the Left/Right key to select Run and press [Enter].

The instrument will enter the battery test mode and wait for the battery test

to be triggered.

6. Press the [On/Off].

7. Based on the selected trigger method, perform the trigger operation.

162

ITech IT6000B Series User Manual
