Quick Reference
Keys Description
[Shift]+[1] (Log) Enter the data logging function menu.
[Shift]+[2] (Lock) Turn the keyboard lock on or off.
[Shift]+[3] (Local) Switch remote control mode to local control mode.
[Shift]+[0] (Recall) Returns the instrument to the specified setup.
[Shift]+[.] (Short) Load mode: Short circuit function key
[Shift]+[+/–]
(Save)
Save the common parameter settings.
1.4 Push-on Knob
The IT6000B series Regenerative Power System provides a knob on the front
panel as shown in the next figure.
The functions of the posh-on knob is described as follows.
• Adjust the value setting
• Select menu item
• Confirm the set value or the selected menu item
Adjust the Value Setting
In the value setting interface, rotate the knob clockwise to increase the set value
and anticlockwise to decrease the set value.
Select Menu Item
The knob can also be used to view menu items. In the menu item display inter-
face, turning the knob clockwise indicates that the next menu item is selected,
and turning the knob anticlockwise indicates that the previous menu item is
selected.
Copyright © Itech Electronic Co., Ltd.
7
