Quick Reference
IO-2. Ps, Not-Invert
Function setting of pin 2
IO-3. Off-Status, Not-
Invert
Function setting of pin 3
IO-4. Ext-Trig, Not-
Invert
Function setting of pin 4
IO-5. INH-Living, Not-
Invert
Function setting of pin 5
IO-6. Sync-On, Not-
Invert
Function setting of pin 6
IO-7. Sync-Off, Not-
Invert
Function setting of pin 7
Ext-Program
External Analog Function. This function is optional. The menu can only
display when corresponding board card is inserted. For details, see
6.12 Source Analogue Function (Ext-Program) (Optional) and 6.13 loa-
dAnalogue Function (Ext-Program) (Optional).
System Reset Select whether to restore the factory default settings or not.
System Rzero
Used to control whether the voltage is quickly zeroed (Source mode
only) after the output is turned off.
• Off: No
• On: Yes
System Info
View the system information. For details, see 6.15 View the System In-
formation (System Info).
AC-Meter
Observe power grid information (Load mode only).
Display Display the current regenerative power value.
Clear Clear the total current regenerative power value.
Disp on timer Screen displays loading time (Load mode only).
On Turn the display on.
Off Turn the display off.
1.9 Options Introduction
The IT6000B series Regenerative Power System supports the following types
of optional accessories (sold separately), the details are as below:
• Optional interface card
– IT-E166: Interface card for GPIB communication. When users need to
use GPIB communication, they can choose to purchase this accessory.
For details, see 2.6.4 GPIB Interface (Optional).
Copyright © Itech Electronic Co., Ltd.
18
