Basic Operation
6.2 Key Lock Function
This function can prevent the power system from the panel keys misoperation
during usage. Press the composite keys [Shift]+[2] (Lock) to lock front panel
keys and the lock symbol “*” is shown on the front panel display. All panel keys,
except the [On/Off] and [Shift]+[2] (Lock) keys, are locked. You can repress
[Shift]+[2] (Lock) to unlock the front panel.
6.3 Save and Recall Operations
The power system can save up to 10 common parameters in nonvolatile memo-
ry (No. 1 to No. 10) for user to recall conveniently. The saved settings include
the following parameters.
Category
Parameter
Main interface
(Source mode)
Voltage setting: Vs
Current setting: Is
Upper limit of voltage: Vh, and lower limit of voltage: Vl
Upper limit of current: I+, and lower limit of current: I-
Upper limit of power: P+, and lower limit of power: P-
The output status of the instrument: [On/Off]
Config menu
(Source mode)
CC/CV loop priority mode: Mode
CC/CV loop speed: Speed
Voltage/Current rise time: V-Rise Time/I-Rise Time
Voltage/Current fall time: V-Fall Time/I-Fall Time
On/Off switch delay: On Delay/Off Delay
Internal resistance of the power supply: Output Res
Protect menu
(Source mode)
OCP/OVP/OPP/UCP/UVP switch status: On/Off
OCP/OVP/OPP/UCP/UVP limit setting: Level
Copyright © Itech Electronic Co., Ltd.
170
