Power Supply Function
• ISO21848
• SAEJ1113–11
• LV123
• LV124
• LV148
• ISO21780
The following is a general overview of this function menu, and the detailed pa-
rameters of the waveform corresponding to each protocol/standard can be
found in the corresponding chapter.
• If there is a waveform parameter related to setting the voltage value,
when the upper limit of the voltage setting defined in the regulation
exceeds the rated voltage of the instrument, the rated voltage of the
instrument is set as the upper limit. Otherwise, the output wave-
form may be distorted.
• Some voltage level models may not have certain automotive wave-
forms. For example, 80V voltage level models do not support LV123
high-voltage automotive waveforms.
Road-
Vehicles
Vehicle waveform function menu
DIN40839
Evaluation of automotive starting
waveform
ISO16750-2
Simulate the waveform to verify the
anti-interference performance of the au-
tomotive electronics’ products.
ISO21848 42V Road vehicles — Electrical and
electronic equipment for a supply volt-
age of 42 V — Electrical loads
SAEJ1113-11 SAEJ1113-11 Waveform protocol
LV123 LV123 Waveform protocol
LV124 LV124 Waveform protocol
LV148 LV148 Waveform protocol
ISO21780 ISO21780 Waveform protocol
