Quick Reference
Copyright © Itech Electronic Co., Ltd. 10
Voltage Limit(V):
Configure voltage output limit
Current Limit(A):
Configure current output limit
Output Delay(s)
Configure output delay
Conf2
Source Config
Source configuration information
Output-off States:
Configure the Output-off state: High
Impedance, Normal, Zero, Relay off
OCP State:
Configure over-current protection:
ON or OFF
Trace State:
Configure channel output On/Off
synchronizing function: ON or OFF
Trigger Mode:
Configure trigger mode: Internal
(Manual trigger),
Bus (Command trigger) or External
(External signal trigger)
Ext_ON/OFF State:
Configure external On/Off control
state: ON or OFF
Ext_ON/OFF Mode:
Configure external On/Off control
mode: Latch or Live
Digital Function
Digital function selection: RIDFi
(power fault indication mode) or
DIGio (common digital I/O interface)
Conf3
Calibration Zero
Calibration zero
Current Low Range
Set small current zero calibration: On
(turn the zero calibration function
on), Off (turn the zero calibration
function off), Cal (when the zero
calibration function is turned on,
operate the small current zero
calibration)
Note
For IT6402/IT6412/IT6412S power supply, Conf1 and Conf3 are for configuration of
related menus of single channel, i.e., Channel 1 and Channel 2 should be configured
separately. Conf2 is for configuration of related menus of 2 channels, i.e., the
configuration displayed in the Conf2 interface will work for both Channel 1 and Channel 2
at the same time.
Configuring the Output Speed
This option is used for configuring the output speed. The maximum output
speed under Normal mode is 5ms. If a higher speed is required, switch to the
Fast mode, under which, 150us is available at maximum.
Configuring Voltage Range
This option is used for configuring the voltage output range: High and Low.
IT6411/IT6412 power supply has two output ranges for switchover: High and
Low. The current range changes with the voltage range. IT6402/IT6431/IT6432/
IT6433/IT6411S/IT6412S/IT6432S output power supply has only a single range
- High range for usage. As shown below.
Model
Voltage
range
Voltage output range
IT6402
High
CH1: -6V ~ +6V
CH2: 0 ~ +6V
