ITech IT6400 Series User Manual

Quick Reference
Copyright © Itech Electronic Co., Ltd. 12
Filter
Filter
Filter configuration
Filter Channel:
Channel selection: Channel 1, Channel 2.
(Only IT6402/IT6412/IT6412S contain
this menu.)
Filter State:
Configure the filter state: ON or OFF
Filter Type:
Configure the filter algorithm type:
Average filtering (Average)
Hanning filtering (Hanning)
Rectangle filtering (Rectangle)
Sample Rate
Sample rate: 30KHZ at maximum
Sample Count:
Sample count: 600 points at maximum
Buffer
Buffer
Buffer configuration
Buffer Channel:
Channel selection: Channel 1, Channel 2.
(Only IT6402/IT6412/IT6412S contain
this menu.)
Buffer Size:
Buffer size: (1~ 1,024)
Buffer Statistics:
Statistics: Mean Peak, Max and Min
Buffer Mode:
Buffer control mode: Always (FIFO), Next
(Repetition), Never (OFF)
Auto Clear:
Automatic clear when full: ON or OFF
Export To USB:
Export to the USB (BufCH1_xx.txt)
Configure buffer
The buffer will collect the measurement results and data till full. The collected
data comprise voltage and current measurement data. The User can configure
the following parameters for buffer functions:
⚫ Buffer Channel: Select the Buffer function in Channel 1 or Channel 2.
⚫ Buffer Size: Buffer size. Maximum buffer size of each channel will be
1,024 pcs of data.
⚫ Buffer Statistics: Statistics option. If the data are to be saved in the butter,
the statistic data can be calculated, like: Mean, Peak, Max and Min
⚫ Buffer Mode: Save control mode. Including Always (FIFO, first in and first
out of data in the buffer area), Next (Repetition, enable write protection till
the buffer area is full) and Never (OFF, disable write protection for the
buffer area).
⚫ Auto Clear: Auto clear the buffer. ON or OFF
⚫ Export To USB: Export the buffer data to the USB (BufCH1_xx.txt)
