星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
diameter line constituted by the first and the second points, and distance from the diameter
line is the radius of the round.
If it needs to adjust the stitch, speed, fastening, complementary sewing, zig-zag sewing
and insert functional code at the end of this section, please refer to relevant setting operations.
This operation may be done at any time before the graphics generation.
4.7 Multi-Segment Collection
In file collection main interface, press the key, the key background becomes
yellow, shows that the current section of collection is multi-segment mode, as shown in
figure:
In multi-segment collection, it can collect 127 points continuously at most, to generate
line segments by the way of two points a straight line.
Absolute origin or the end point of previous collection section is the first point of
multi-segment collection. Press keys to move the cursor to the needed position, press the
key to determine the collection point; move for many times and determine the
collection point; after completing, press the key to generate the multi-segment
connecting each point.
If it needs to adjust the stitch, speed, fastening, complementary sewing, zig-zag sewing
and insert functional code at the end of this section, please refer to relevant setting operations.
