星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
7.3 Export Parameters
It is used to export all set parameters of the system to the U disk as a backup, it can be
imported to use from the "Ex-Factory Parameters" interface of main menu interface. It is
suggested to export system parameters to the U disk for backup in use for the first time.
The effect of parameters file exported from the machine is best for the same machine;
Due to the nuances of the machine, if it is used for other machine of the same model, it can be
used but may not be able to achieve the best effect of the work. Do not mix parameters of
different models.
The detailed steps to export parameters are as follows:
a) Insert U disk;
b) Enter the "Aided Design" interface, click "Export Parameters"
c) In the pop-up "Machine Type" dialog box, enter the number as file name of the
exported parameters, click "OK"
d) Wait for several seconds until the pop-up prompts "Export parameters successfully,
please return", click "Exit". It means that parameters are exported successfully,
and .XHP parameter file will be generated in root directory of the U disk. After that
you can remove the U disk.
Note: please do not remove the U disk during the prompt popping up after clicking on
"Export Parameters"! Otherwise it may cause damage to the U disk file.
7.4 Output Detection
It is used to test whether the output control is normal.
In auxiliary operation interface, press the button to enter the output test
interface, as shown in figure:
