星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
5.7 Append Needle Point
In the edit file main interface, press the button to enter select stitch interface, as
shown in figure:
Press the Single Step or Continue key to move the cursor forward and backward to the
needed position; press the key to enter append single needle operation interface by
default. After the completion of appending, subsequent stitches will move as a whole.
There are two ways to append stitch: Append one stitch;
Append multiple stitches.
5.7.1 Append Single Needle
In the append stitch interface, press the button to enter append single needle
operation interface, and the icon background will become yellow. As shown in figure:
