星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
It will return to the select stitch interface automatically, and you can continue to edit or
click button to save the changes and return to the edit file main interface.
In the graph offset interface, set offset for “X: 0.0 Y: 9.0” and contrast of effect before
and after the modification is as follows:
5.13 Secondary Origin Modification
In the edit file main interface, press the button; if there is no secondary origin in
the graphic, it will prompt "No secondary origin found, please return!" directly; if yes, it will
enter the modify secondary origin (offset point) interface, as shown in figure:
Press the direction keys to move the cursor to the starting position where it needs to
modify, and press the key to complete modification.
It will return to the select stitch interface automatically, and you can continue to edit or
click button to save the changes and return to the edit file main interface.
Secondary origin (offset point) only exists in the empty offset section between the
graphics connection absolute origin and the point of first start sewing. Refer to the "Collect
To Next Page
