Jack 6040-D - Append Multi-Needle

星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
48
Press the direction keys to move to the position where it needs to append stitch, the X, Y
positions above direction keys display the relative coordinates of cursor with the selected
point; move the cursor for not more than 12.7 MM, and press the key to complete
appending.
It will return to the select stitch interface automatically, and you can continue to edit or
click button to save the changes and return to the edit file main interface.
5.7.2 Append Multi-Needle
In the append stitch interface, press the button to enter append multi-needle
operation interface, and the icon background will become yellow. As shown in figure:
Press numeric keys to input the number of threads needed to append, the appended stitch
is the direction and stitch length of the needle before the append point, and press the
Exit
OK
Exit
OK
