Jackson crew series - Page 20

11
07610-003-78-18-N
Volts Phase Freq
Wash
Motor
Amps
Drive
Motor
Amps
Wash
Heater
Amps
Total
Load
208 1 60 10.0 1.8 72.1 83.9
230 1 60 10.0 1.8 *59.9 71.7
240 1 60 10.0 1.8 62.5 74.3
208 3 60 8.6 1.1 41.6 51.3
230 3 60 8.4 1.1 *34.6 44.1
240 3 60 8.4 1.1 36.1 45.6
460 3 60 4.2 0.6 **17.3 22.1
480 3 60 4.2 0.6 18.1 22.9
44" with 15 kW Wash Heater
Volts Phase Freq
Wash
Motor
Amps
Drive
Motor
Amps
Wash
Heater
Amps
Total
Load
208 1 60 10.0 1.8 86.5 98.3
230 1 60 10.0 1.8 *71.9 83.7
240 1 60 10.0 1.8 75.0 86.8
208 3 60 8.6 1.1 50.0 59.7
230 3 60 8.4 1.1 *41.5 51.0
240 3 60 8.4 1.1 43.4 52.9
460 3 60 4.2 0.6 **20.8 25.6
480 3 60 4.2 0.6 21.7 26.5
44" with 18 kW Wash Heater
Volts Phase Freq
Wash
Motor
Amps
Drive
Motor
Amps
Total
Load
208 1 60 10.0 1.8 11.8
230 1 60 10.0 1.8 11.8
208 3 60 8.6 1.1 9.7
230 3 60 8.4 1.1 9.5
460 3 60 4.2 0.6 4.8
44" Steam
* Denotes 240 volt heating elements that have been down-rated when 230 volts is applied.
** Denotes 480 volt heating elements that have been down-rated when 460 volts is applied.
SPECIFICATIONS
ELECTRICAL REQUIREMENTS
