12
07610-003-78-18-N
Volts Phase Freq
Pre-Wash
Motor
Amps
Wash
Motor
Amps
Drive
Motor
Amps
Wash
Heater
Amps
Total
Load
208 1 60 10.2 10.0 1.8 86.5 108.5
230 1 60 9.4 10.0 1.8 *71.9 93.1
240 1 60 9.4 10.0 1.8 75.0 96.2
208 3 60 6.8 8.6 1.1 50.0 66.5
230 3 60 6.4 8.4 1.1 *41.5 57.47
240 3 60 6.4 8.4 1.1 43.4 59.3
460 3 60 3.2 4.2 0.6 **20.8 28.8
480 3 60 3.2 4.2 0.6 21.7 29.7
66" with 18 kW Wash Heater
Volts Phase Freq
Pre-Wash
Motor
Amps
Wash
Motor
Amps
Drive
Motor
Amps
Total
Load
208 1 60 10.2 10.0 1.8 22.0
230 1 60 9.4 10.0 1.8 21.2
208 3 60 6.8 8.6 1.1 16.5
230 3 60 6.4 8.4 1.1 15.9
460 3 60 3.2 4.2 0.6 8.0
66" Steam
* Denotes 240 volt heating elements that have been down-rated when 230 volts is applied.
** Denotes 480 volt heating elements that have been down-rated when 460 volts is applied.
Volts Phase Freq
Rinse
Heater
Amps
208 1 60 57.7
230 1 60 47.9
208 3 60 33.3
230 3 60 27.7
460 3 60 13.8
40 °F Rise – 12 kW Booster
Volts Phase Freq
Rinse
Heater
Amps
208 1 60 82.7
230 1 60 71.9
208 3 60 47.7
230 3 60 41.5
460 3 60 20.7
70 °F Rise – 18 kW Booster
Note: On the 208 volt machines, the rinse heater is actually rated at 17.2 kW.
Volts Phase Freq Amps
208 3 60 32.2
230 3 60 22.9
460 3 60 13.4
Blower/Dryer
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
