Jackson crew series User Manual

16
07610-003-78-18-N
CHEMICAL TUBE
INSERTION POINT
875"
INLET WATER FITTING
1/2" NPTF
MAIN ELECTRICAL
CONNECTION OPENING
1.375"
BOOSTER HEATER
ELECTRICAL CONNECTION
OPENING
1.375"
SHOWN FROM REAR OF LEFT TO RIGHT UNIT.
RIGHT TO LEFT UNIT IS MIRRORED
DETERGENT INJECTION POINT.
ANOTHER BULKHEAD PLUG
IS PROVIDED ON THE LEFT SIDE
OF THE UNIT
ADJUSTABLE BULLET FEET
1-1/2" NPTF DRAIN CONNECTION
BULKHEAD OPENING FOR
CONDUCTIVITY PROBE
INSTRUCTIONS
INSTALLATION
