Software Version 5.0
25/11/02 Draft Page 21
NOTE: When a channel is inhibited the LED in the associated Flash button flashes
on and off. It is not possible to inhibit the channels which do not have Flash buttons –
i.e. the Virtual fader channels.
7.5 Add / Solo Fader
This fader scales the level of the Flash buttons.
7.6 Grand Master (GM) Fader
This fader scales the level of all console intensity outputs except the Flash buttons.
7.7 Rate Control
The Rate Control scales the speed of all Chases that are running. This control should
normally be set to the middle detent or 12 o’clock position. Chases will then run at the
speed set in the Chase menu.
7.8 Fixture Fader
The Fixture Master fader scales the overall level of the Assign Master faders.
