JANDS – Event 4 Version 5 Users Manual
Page 26 Revision 5.0.0.5 25/11/02
8.4 Programmer Buttons
Press Clear to release control from the
Programmer. When pressed, all fixtures and
scrollers go to the previous state, ie. all
parameters snap to the values they were before
loading the Programmer.
Shift + Clear to send all fixtures and scrollers
to their default values, as specified in the
fixture library.
Shift + Pg1, Pg2, Pg3 to access the 3
pages for each palette.
Press to select the palette.
Press & hold to fan fixture positions (except
Scroller).
Press to select the palette
Press & hold to fan fixture Position, Colour or
Beam.
Press & hold to enable or disable palette timing
(see below).
Snap
Palette fade time can be set in the Setup Prefs
Ptime field. Press and hold Position, Colour or
Beam and press this button to toggle between
Snap and use Time
Shift + Position to open the EFFECTS
palette.
The Effects Palette cannot be modified.
8.5 Palette Buttons
The 20 palette buttons are used to select Fixtures and palettes.
Patching Fixtures and Scrollers automatically programmes the
Fixture and Scroller buttons. The other Palettes i.e. Position,
Colour, Beam, and Group must be recorded as detailed below.
The LED in each palette button illuminates when it is selected.
Selection Shortcuts for Fixtures, Scrollers & Groups
Press a button to select a Fixture, Scroller or Group. Press again
to deselect
Hold down one palette button and then press another to select or
deselect all scrollers between the two buttons.
Deselect ALL selected fixtures and select a single fixture by
Double Clicking a button
