JANDS – Event 4 Version 5 Users Manual
Page 30 Revision 5.0.0.5 25/11/02
8.5.3 Fan
Fanning Intensity, Position, Colour or Beam is a convenient way to spread the
intensity position colour or beam of a group of fixtures. For example by fanning
position a group of fixtures can be made to all point inwards to a point or outwards
like a fan. A minimum of 2 lights must be selected to use Fan.
Press and Hold Position, Colour or Beam to open the Fan controls:
Fan Fixt Start Mid End Snap
FF%Intensity 50%Pan 0%Tilt
The soft buttons above the LCD are used to select how the fixtures fan:
Start Select Start to fan fixtures towards or away from the lowest numbered
fixture
Mid Select Mid to fan fixtures towards or away from the middle numbered
fixture
End Select End to fan fixtures towards or away from the higest numbered
fixture
Snap This button is not used for fan. It is used to set palette timing on or off –
refer to section 17.5.5
The wheels can be used to make the following adjustments to the effect:
Pan Rotate the Pan wheel anti-clockwise to fan Pan inwards. Rotate the Pan
wheel clockwise to fan Pan outwards.
Tilt Rotate the Tilt wheel anti-clockwise to fan Tilt backwards. Rotate the Pan
wheel clockwise to fan Pan forwards.
Fan works, not only on position but also on Intensity, Colour and Beam. Fanning
colour creates staggered hues and rainbow like effects.
Fanned parameters are stored in Memories and Chases as Levels not Palettes.
