8.5.1 Programmer LCD Soft Buttons
The “Soft” buttons located above the programmer LCD provide a number of functions
depending on which Palette is active. Some functions are common to more than one
palette.
Next
The Next button is used to quickly step through a number of
Fixtures, Scrollers or Groups highlighting one at a time. When
Next is pressed any selected items are deselected and their
intensity is set to 15% (Note1). Then the next highest numbered
item is selected and its intensity is set to full (Note1).
Press Shift + Next to select the Previous fixture.
0↕100
The 0↕100 button toggles the Intensity of the selected Fixtures or
Scrollers between 0 and full.
Flip
The Flip button is used to find alternative settings of the pan
and tilt of selected moving yoke fixtures so that the beam will
point in the same direction. This feature is not available for
moving mirror fixtures.
Active
Fixture Function Only:
The Active button is used to select any Fixtures that have
intensity greater than 10%. This provides a quick method of
taking control fixtures during playback.
Pg 1..4
Scroller Function Only:
The Pg1 – Pg4 buttons are used to select the active page if more
than 20 scrollers are patched. Up to 4 pages of 20 scrollers can be
patched and the active page number flashes on the LCD.
If G =
Group Function Only:
The If G= button is used to select any Fixtures that are active
and are part of a particular Group palette. This provides a quick
method of taking control of fixtures during playback.
Step
Colour Palette Only:
The Step button is used to move the colour parameter wheel
labels one position to the left. This feature is designed to be used
with fixtures that have a colour wheel and colour mixing (RGB,
CMY) controls. Pressing Step with these fixtures will move the
RGB or CMY parameters onto the left, mid and right wheels.
