JANDS – Event 4 Version 5 Users Manual
Page 24 Revision 5.0.0.5 25/11/02
8.3 The Programmer
The Programmer section is used to manually control and programme fixtures (moving
lights) and Colour Scrollers.
The six function buttons above the programmer LCD are used to select which function
is active on the wheels and palette buttons. For example, when the Fixture button is
pressed, the palette buttons are used to select fixtures and the wheels are set to control
Intensity and movement. When the Colour button is pressed, any selected fixtures can
be set to a colour using the wheels or the colour palette buttons (if programmed).
8.3.1 The Programmer LCD
The programmer LCD shows labels for the buttons above it and the wheel below it.
However when the Record button is held down it also displays and provides quick
access to the Record options menu.
The top line of the LCD displays the current programmer function and labels for the
unmarked buttons above the LCD.
The bottom line of the LCD displays current settings and labels for the wheels beneath
the LCD.
Note The Programmer defaults to Fixture selection mode after being cleared. To
completely close the Programmer press the button above the LCD marked Exit
8.3.2 Position, Colour and Beam
Press the Position button to make adjustments to selected fixtures’ intensity, pan, and
tilt settings using the wheels.
Programmer LCD Position Display:
F Posn Pg1 Next 0↕100 Flip If P=
0%Intensity 50%Pan 50%Tilt
Press the Colour button to make adjustments to selected fixtures’ colour settings
using the wheels.
Programmer LCD Colour Display: (CMY, colour mixing fixture)
F Colr Pg1 Next Step If C= More
0%Cyan 50%Magenta 53%Yellow
