Software Version 5.0
25/11/02 Draft Page 61
17 The Setup menus
The Setup menu contains a number of submenus that can be used to configure various
console function and controls.
Set Desk Ptch Ctrl Heat Rec Pref Bkup
Up +to| +to| +to| +to| +to| +to| +to|
Move the cursor to any field any press the + (On) key to open a submenu.
17.1 Setup Desk Submenu
Press Setup and open the Desk submenu to configure the console and various
optional accessories.
Set Mode Wide Link Display Midi
Desk Rec +to| +to| +to| +to|
17.1.1 Setup Desk Mode - Restricting Access
Mode This field can be changed to restrict access to various console functions .
In Rec (Record) mode all console functions are available. In Play
mode the following menus and menu fields are not available: Memory,
Edit, Chase, Page Label, File Save, Patch, Clear, File Label.
17.1.2 Setup Desk Wide – Setting Fader (Desk) Channels
The Setup Desk Wide submenu is used to configure the physical preset Faders into
either a single preset or as dual presets. The menu is also used to create additional
virtual Fader channels that do not have a physical fader associated with them. For
usage details, see section 8.2
Press Setup, open the Desk submenu and open the Wide submenu to configure the
faders
Set Presets Faders Confirm
Wide Dual 24 Off
Presets This field changes to the function of the lower set of Preset Faders . In
Dual mode the faders act as preset 2. In Single mode the lower set of
faders act as an extension of Preset 1.
When the console is in Single Preset mode the Preset switch (located above the
Fixture fader in the master section) is used to swap the flash buttons between the
upper and lower sets of faders.
Once a console has been set to Single Preset Mode the Preset 2 faders are used to
control the higher numbered channels. For example, on an EVENT 408 the Preset 2
faders would control channels 25 to 48. The Preset 2 Master fader is disabled.
Move the Cursor to the Faders field and enter the total number of Fader channels
required (1 – 240).
