Jands Event 4 User Manual

JANDS – Event 4 Version 5 Users Manual
Page 76 Revision 5.0.0.5 25/11/02
21 Appendix A - Pin Assignments
21.1.1 DMX Digital Output Sockets
PIN No Signal
1 SHIELD
2SIGNAL –
3SIGNAL +
4 NOT USED
5 NOT USED
Connector type: 5 pin AXR RS-485 Standard USITT DMX-512 Protocol
21.1.2 MIDI In, Thru, Out Sockets
PIN No Signal
1 NOT USED
2 NOT USED
3 NOT USED
4 MIDI +
5 MIDI SIGNAL
Connector type: DIN 5 pin
21.1.3 Desklight Socket
PIN No Signal
1 No Connection
2 Ground
30 to +12 volts
Connector type: 3 pin AXR
21.1.4 Desk Link Cable
To link two Event 4 desks together connect a MIDI cable from the MIDI output of the
slave desk to the MIDI input on the master desk.
21.1.5 Power
Power Requirements: 90 volts to 265 volts AC, 50-60 Hz
Power Consumption: 40 watts
Power Connector: IEC 3-pin inc. fuse, switch and mains filter
Power Fuse: 2 amp M205
