Jandy APUREM User Manual

WARNING
When using electrical products, basic precautions should always be followed, including the following:
• RISK OF ELECTRIC SHOCK WHICH CAN RESULT IN SERIOUS INJURY OR DEATH. Before
attempting installation or service, ensure that all power to the device is disconnected/turned off at
the circuit breaker.
• Groundingisrequired.Theunitshouldbeinstalledbyaqualiedservicerepresentativeand
should be properly grounded. (See Section 3.4, Earth Grounding).
• Install to permit access for servicing.
• Read Section 1, Important Safety Instructions. Before attempting any electrical wiring, be
sure to read and follow Safety Instructions. Wiring should only be attempted by a qualied
professional.
3.2 Plumbing Congurations
3.2.1 Recommended Electrolytic Cell and Sensor Orientation
Shown below are three (3) different cell and sensor orientations. The third port on the cell is designed for
installation of the sensor and for quick viewing of the cell plates.
Section 3. Installation Instructions
3.1 Materials and Tools
NOTE Salt not included. See Section 4, Pool Water Preparation.
Installation Materials Furnished
PureLink
TM
Integrated Power Center (in lieu pf AquaPure control
center)
(1 ea.) PureLink power center (Standard or Breaker)
(2 ea.) Wire Nuts
(1 ea.) Installation Template
PLC700 / PLC1400 Cell Kits
(1 ea.) Electrolytic Cell with 2”-2½” Universal Unions
(1 ea.) Sensor with 16 ft (4.88m) Cable and O-ring
(1 ea.) Universal Union Nut
(1 ea.) 16 ft (4.88 m) DC Power Cord
(1 ea.) Strain Relief
(1 ea.) Owner’s Manual - Warranty Information
AquaPure Control Center (PureLink™ not used)
(1 ea.) AquaPure Control Center
(2 ea.) Wire Nuts
(1 ea.) Installation Template
Tools Needed for Installation
Tape Measure
Phillips & Flathead Screwdrivers
Pliers
Hacksaw
Voltmeter to determine line voltage of AC wiring to power supply
Electric Drill Motor and 1/4 “ masonry drill bit for mounting power
supply on block or stucco wall
An NSF
®
*approved All Purpose Cleaner Primer
An NSF approved All Purpose Cement (such as Weld-On
®
794™,
793™)
* NSF is a registered trademark of the NSF International.
Page 12
ENGLISH
Page 12
ENGLISH
Jandy
®
AquaPure
®
/PureLink™ Power Center and Cell Kit
|
Installation and Operation Manual
