PureLink
Power Center
(for PureLink
systems)
• The PureLink
TM
system integrates a salt water chlorinator control system and
power center for use with AquaLink Pool/Spa Automation systems (not including
AquaLink Z4).
• The LCD display on the user interface offers monitoring of chlorine production,
cell modes, salinity level, temperature, water ow and diagnostics.
• The chlorine generator electronics inside the power center are connected with the
pool circulation pump electrical source so that the electrolytic cell only operates
when the pool pump is on. The ow portion of the Flow/Temp/Salinity Sensor is
a backup device only.
Electrolytic Cell
The electrolytic cell contains bipolar electrodes which perform the electrolysis and
produce chlorine when energized with DC current. Chlorine is generated as pool
water containing salt passes through the cell. The chlorine production can be varied
by either adjusting the chlorine production level on the power center or by varying
the number of hours the unit is on each day. The system automatically cleans the
cell’s electrode plates once every 3 hours by reversing the polarity of the electrical
current. Whether the system is in forward or reverse, it is still producting chlorine.
Flow/
Temperature/
Salinity/Sensor
The ow portion of the ow/temp/salinity sensor detects if there is adequate water
ow through the cell. The salinity portion of the ow/temp/salinity sensor detects the
level of salt in the pool water. This salt level is displayed in grams per liter (GPL)*
on the user interface liquid crystal display (LCD) whenever the salinity button is
pressed. This eliminates the need to manually test the salinity of the pool water. The
pool temperature is displayed by pressing the Temperature button.
*1 gram per liter (GPL) = 1000 ppm (parts per million)
2.2 Electrical Specications
700 Model 1400 Model
Input: 120 VAC, 50/60 Hz, 1.5 AMPS
240 VAC, 50/60 Hz, 0.75 AMPS
Input: 120 VAC, 50/60 Hz, 2.5 AMPS
240 VAC, 50/60 Hz, 1.25 AMPS
Output: 27 VDC @ 3 AMPS maximum Output: 27 VDC @ 6 AMPS maximum
Chlorine: 0.625 lb. / 24 Hr. (283 gm / 24 Hr.) Chlorine: 1.25 lb. / 24 Hr. (567 gm / 24 Hr.)
External
Control:
ORP/External Control Connector
AquaLink RS485 Connector
External
Control:
ORP/External Control Connector
AquaLink RS485 Connector
CAUTION
The electronics for the salt water chlorinator are factory wired for 240 VAC service. If the
available electrical service is 120 VAC then the power supply wiring must be changed to operate on
120 VAC as shown in Figure 2b.
The chlorinator’s electronics are powered from the LOAD SIDE of the pool circulation pump relay;
therefore, if the available electrical service is 120 VAC, then the pump must also be wired for 120
VAC.
Page 8
ENGLISH
Page 8
ENGLISH
Jandy
®
AquaPure
®
/PureLink™ Power Center and Cell Kit
|
Installation and Operation Manual
