Jandy APUREM - Figure 2 A. Wiring Diagram for the Purelink

Figure 2a. Wiring Diagram for the PureLink
TM
System with a 240 VAC Filter Pump
PRIMARY
SECONDARY
J10 J8
CHLORINE GENERATOR
POWER INTERFACE
J13
J12
J11
GR
Y
BK
R
CHLORINE GENERATOR
USER INTERFACE
Filter Pump Relay
Aux.3Relay
Load 2
Line 1
Wire Nut to
120 VA C Power
Breakers
Ground
Neutral
Blower
(120 VAC)
Filter Pump
(240 VAC)
To Electrolytic
Cell
Multiplex Board
(J1 through J4)
J1J2J3J4
Load 1
Line 2
Low voltage raceway (do not run high voltage in this compartment)
(Middle primary wires not used)
Factory wired to Multiplex Board
To AquaLink
®
24VAC
120VAC
AQUALINK RS
POWER TRANSFORMER
BLK/YEL
BLACK
Flow, Salinity, Temp Sensors
HEAT SINK
L - BRACKET
CHLORINE GENERATOR
TRANSFORMER
Page 9
ENGLISH
Page 9
ENGLISH
Jandy
®
AquaPure
®
/PureLink™ Power Center and Cell Kit
|
Installation and Operation Manual
