Janus Mv Series User Manual

Page: 46
MV & LV SERIES ENGINEERED DRY CHEMICAL FIRE EXTINGUISHING SYSTEM
OPERATION, DESIGN, & SERVICE MANUAL
REV C
Document # DOC324
Issued: April 26, 2018
Revised: March 22, 2022
UL FILE # EX27541
Section 3 System Design
12.5 ft
(3810 mm)
16 ft
(4877 mm)
27.2 ft
(8290 mm)
12.5 ft
(3810 mm)
16 ft
(4877 mm)
27.2 ft
(8290 mm)
25 ft
(7620 mm)
16 ft
(4877 mm)
27.2 ft
(8290 mm)
Figure 3.2.4.2c Examples of Module Perimeter Total Flood Coverage Using the TFP Nozzle
Note: When “stacking” modules vertically, the
maximum nozzle height above the cylinder is 12.5
ft (3810 mm).
12.5 ft
(3810 mm)
32 ft
(9753 mm)
27.2 ft
(8290 mm)
