3.4.3.2 Ducts, OFPSB
e D/P Nozzle will protect either round or rectangular ducts up to 28 ft (8534 mm) in length. Any change
in duct direction or additional length requires an additional D/P nozzle. e duct nozzle must be centered
at the duct entrance, pointed in the direction of air flow.
Round Ducts
Maximum Diameter = 46 in (1168 mm)
Rectangular Ducts
e following table shows sample maximum rectangular dimensions, based on the following two
requirements:
Maximum Perimeter = 144.5 in (3670 mm)
Maximum Diagonal = 46 in (1168 mm)
Table 3.4.3.2 Rectangular Duct Dimensions, OFPSB
Side 1,
inch
12 14 16 18 20 22 24 26 28 30 32 32.5 34 36 38 40 42 44
Side 2,
inch,
MAX
44.4 43.8 43.1 42.3 41.4 40.4 39.2 37.9 36.5 34.8 33 32.5 31 28.6 25.9 22.7 18.7 13.4
Side 1,
mm
305 356 406 457 508 559 610 660 711 762 813 826 864 914 965 1016 1067 1118
Side
2, mm,
MAX
1128 1113 1095 1074 1052 1026 996 963 927 884 838 826 787 726 658 577 475 340
Section 3 System Design
