MV & LV SERIES ENGINEERED DRY CHEMICAL FIRE EXTINGUISHING SYSTEM
OPERATION, DESIGN, & SERVICE MANUAL
REV C
Document # DOC324
Issued: April 26, 2018
Revised: March 22, 2022
UL FILE # EX27541
Section 3 System Design
3.3.2.2 Agent Application - Standard Work Area Coverage
For standard work area coverage of a Vehicle Paint Spray Booth, the Total Flood Nozzle (P/N 16172) is
used. Each TF Nozzle must discharge a minimum of 1.48 lbs (0.67 kg) of dry chemical agent per second
(a minimum flow rate of 1.48 lb/s (0.67 kg/s)). e Janus Design Suite® Flow Calculation Software
will determine the amount of dry chemical agent required to meet these flow rates based on the hazard
dimensions and number of nozzles required.
3.3.2.3 Module Perimeter Work Area Coverage
Module Volume: 2,720 ft³ (77.02 m³) per nozzle
Maximum Module Area: 217.6 ft² (20.21 m²) per nozzle for booth up to 20 ft (6096 mm) in height (Refer to Table 3.3.2.3a
and Table 3.3.2.3b)
Maximum Module Height: 20 ft (6096 mm)
Maximum Module Side Length: 16 ft (4877 mm)
Maximum Nozzle Offset From Center of Wall: +/- 10% of adjacent wall length
Table 3.3.2.3b Module Perimeter Vehicle Paint Spray Booth Work Area Coverage, mm
Booth
Height, mm
Module Side 2, mm
4145 4267 4420 4572 4724 4877
3810 4877 4737 4572 4420 4276 4145
3962 4688 4554 4395 4249 4112 3984
4267 4353 4228 4081 3947 3819 3700
4572 4063 3947 3810 3682 3563 3453
4877 3810 3700 3572 3453 3341 3237
5182 3584 3481 3362 3249 3146 3048
5486 3386 3289 3176 3069 2969 2877
5791 3206 3115 3008 2908 2813 2725
6096 3048 2960 2856 2761 2673 2591
Table 3.3.2.3a Module Perimeter Vehicle Paint Spray Booth Work Area Coverage, ft
Booth
Height, ft
Module Side 2, ft
13.6 14.00 14.50 15.00 15.50 16.00
12.5 16.00 15.54 15.00 14.50 14.03 13.60
13 15.38 14.94 14.42 13.94 13.49 13.07
14 14.28 13.87 13.39 12.95 12.53 12.14
15 13.33 12.95 12.50 12.08 11.69 11.33
16 12.50 12.14 11.72 11.33 10.96 10.62
17 11.76 11.42 11.03 10.66 10.32 10.00
18 11.11 10.79 10.42 10.07 9.74 9.44
19 10.52 10.22 9.87 9.54 9.23 8.94
20 10.00 9.71 9.37 9.06 8.77 8.50
