Jay electronique Orion OREL User Manual

- 68 - Orion - 324501H
FR
DEEN
4.3- Orion receivers delivery confi guration
Transmitter buttons
/ receiver relays
association
(All the default
assignments have
been defi ned using
the identity code :
«ON - ON - ON - ON -
ON - ON - ON - ON»)
Receiver on DIN rail ORRD22••• (2+1 or 3 relays) :
- Transmitter buttons B1 and B2 assigned to relays R1 and R2
- «On/R3» relay set for «On» relay»
Receiver ORRS21••• (2 relays) :
- Transmitter buttons B1 and B2 assigned to relays R1 and R2
Receiver ORRS42••• (4+1 relays) :
- Transmitter buttons B1 to B4 assigned to relays R1 to R4
Receiver ORRA82••• (8+1 relays) :
- Transmitter buttons B1 to B8 assigned to relays R1 to R8
Receiver ORRAH2••• (16+1 relays) :
- Transmitter buttons B1 to B16 assigned to relays R1 to R16
Radio channel (1)
Channel nb.17 (434,700 MHz)
Relay operating
mode
«Continuous make contact» Mode
(After having realized a transmitter button / receiver relay
association, when transmitter button is pressed, relay in the
receiver is activated, when button is no longer pressed, the
relay is deactivated)
Interlocking
of confl icting
commands
No interlocking programmed
(1) = The programming of another radio channel number can only be done with a
transmitter equipped with an «On/Off» button
DRAFT a
