7 - Product confi guration
7.1- Confi guration steps to be respected
Before fi nal installation and use, we recommend that you confi gure the units
with customized settings as detailed in steps 1 to 7. These steps must be
performed on an insulated work surface in the workshop.
~ 10 mn
Step 1
Programmation du nouveau code d’identité de l’émetteur
> see chapter Transmitter identity code programming
Step 2
standard confi guration Customized confi guration
Standard association of
transmitter buttons with receiver
relays :
button nb.1 > relay nb.1,
button nb.2 > relay nb.2
etc...
(Previous settings are
automatically erased)
> see chapter
«Standard»
Transmitter / Receiver
association
or
Receiver pre-settings erased
> see chapter Receiver
parameter erasing procedure
Customized association of
transmitter buttons with receiver
relays
> see chapter «Customized»
Transmitter / Receiver
association
Step 3
(Optional)
Operating mode programming procedure for function relays
> see chapter Programming of relay operating modes
Step 4
(Optional)
Interlocking of confl icting commands programming procedure
> see chapter Programming of confl icting command interlocking
Step 5
(Optional)
Radio channel programming procedure
> see chapter Programming of confl icting command interlocking
Step 6
(Optional)
«Standby» function time programming procedure
> see chapter «Standby» function time programming (Automatic
shutdown of transmitter)
Step 7
Proceed to the installation on site by respecting the installation
recommendations described in chapter Installation and use
recommendations
