- 93 -Orion - 324501H
DE
FREN
5
If the transmitter has a «On/Off» button, turn on the transmitter.
6
Press simultaneously on both transmitter buttons controlling relays that must
be interlocked.
V2
and
V3
ORRA
ORRS
ORRD
LEDs blink alternatively, then go off, The receiver
recorded the interlocking of two relays.
7
Repeat point n°6 if other interlocking must be realized.
8
Once the programming procedure is fi nished :
ORRS and ORRA receivers : switch off the receiver and remove the
ORRD receiver : set the microswitch to the «OFF» position
7.7.1- Particularity of the «bistable ON/OFF» relay operating
mode
In the «bistable» relay operating mode, the confl icting commands are
not necessarily simultaneously emitted, in that case a priority is given to
the last pressed button.
Example: interlocking between the button no.1 and the button no.2 in
«bistable» relay operating mode.
An impulse on the button no.1 activates the relay no.1 (and remains
activated), an impulse on the button no.2 deactivates the relay no.1 and
activates the relay no.2.
7.7.2- Particularity of ORRA industrial receiver, «large model»
The interlocking functions are distributed among 4 relay groups :
Group 1 : relay nb.1 (R1) to relay nb.4 (R4),
Group 2 : relay nb.5 (R5) to relay nb.8 (R8),
Group 3 : relay nb.9 (R9) to relay nb.12 (R12),
Group 4 : relay nb.13 (R13) to relay nb.16 (R16)..
Example : interlocking is possible between relay R1 and relay R3 but
not possible between relays R1 and R6.
The interlocking functions can only be programmed for this receiver
on relays belonging to a same group.
