3.4- Operation of «RM» relay
Certain receiver models are equipped with an « RM » relay.
This relay can be directly activated and deactivated using the
transmitter « On/Off » button (available depending on model)
; it can also be activated at the same time as a function relay
(common relay).
Descriptions of 2 operating modes for this relay :
Mode 1 (by default) : «On/Off»
Note : the transmitter must be equipped with an « On/Off » button
- The «RM» relay contact is closed and remains closed on the
1st push on the transmitter «On/Off» button *.
- The contact opens in case of radio jamming (>1s) while a
transmitter function button is pressed, and remains open until
radio link is re-established.
- The contact opens and remains open if the transmitter «On/
Off» button is pressed a second time*.
* = Only if the radio link between the transmitter and the receiver is possible
Mode 2 : «Common relay»
Note : this operating mode does not require a transmitter equipped
with an «On/Off» button ; refer to the programming
procedure in the «Confi guration of RM relay» section.
- The «RM» relay contact is closed when at least one of the
function relays is activated.
- The contact opens if none of the function relays is active or if
the receiver is switched off or in case of radio jamming (>1s)
while a transmitter function button is pressed.
