Jay electronique Orion OREL User Manual

- 70 - Orion - 324501H
FR
DEEN
5.3- Transmitter accessories
Reference Description
OWE10
Carrying clip (on support OWE01, belt, pocket ..) (see installation in appendix
G) (1)
OWE20
Neck strap
OWE13
Case for standard (ORET) or industrial (OREi) transmitter
OWE14
Case for standard (ORET) or industrial (OREi) transmitters
OWE30
Protective foam for multifunction (OREL) transmitter
UBWE34
Case for multifunction (OREL) or industrial (OREV) transmitters
OWE01
Mounting support for all transmitter models with carrying clip
ORCL
Mounting support for multifunction transmitter (OREL)
ORCL1
12-24 VDC (vehicle connector) / 9 VDC charger support unit + 3 accumulators
AAA type, for multifunction transmitters (OREL) with accumulators
ORCLU
230 VAC (EU, UK, US plugs) / 9 VDC charger support unit + 3 accumulators AAA
type, for multifunction transmitters (OREL) with accumulators
OWE301
60 black/white rectangular function labels for standard, industrial and multifunction
transmitters (4, 6 or 8 buttons) (1)
OWE403
96 black/white round labels for multifunction transmitters (12 or 16 buttons) (1)
(1) = 1 accessory is supplied with transmitter.
5.4- Receiver accessories
Reference Description
OWR01
BNC plug-in antenna kit (see installation kit in appendix E) (2)
OWR02
Internal antenna kit (see installation kit in appendix F) (3)
OWR38
Fastening Kit for ORRS receiver by 2 magnetic contacts
UDWR38
Fastening Kit for ORRA receiver by 4 magnetic contacts
VUB084
1/4 wave antenna straight, 433MHz band, BNC (4)
VUB086
1/2 wave antenna straight, 433MHz band, BNC (4)
VUB060
90 ° BNC elbow for antenna VUB084 or BNC antenna extension (4)(5)
VUB170
0,5m extension for BNC antenna (4)
VUB105
2m extension for BNC antenna + mounting bracket (4)
VUB125
5m extension for BNC antenna + mounting bracket (4)
VUB131
10m extension for BNC antenna + mounting bracket (4)
(2) = BNC antenna and BNC extension to be ordered separately.
(3) = 1 kit is supplied with industrial receivers.
(4) = Except for the DIN rail model which comes with a BNC antenna connector as a
standard feature, the other receiver models require the plug-in antenna kit OWR01
for use of an antenna or a plug-in antenna extension.
(5) = Not suitable for direct connection to antenna VUB086 ; in this case, use an
intermediate extension type VUB1••.
DRAFT a
