If the above requirements cannot be observed (case of ORRD receiver
installed in cabinet), an external antenna must be used with extension
(BNC connection). External antenna and extension must be ordered
separately, see chapter Receiver accessories.
For the ORRS and ORRA receivers, use of an external antenna requires
that the user purchases and installs the plug-in antenna kit, reference :
OWR01. see kit installation in appendix E.
Type of receiver installation
(with plug-in antenna)
Reference suggestion of antenna and extension to be used
Outside installation
Antenna VUB084 or antenna VUB086
(possible use of extension with support VUB105/VUB125/VUB131)
Installation on vehicle
Antenna VUB084 + extension with support VUB105/VUB125/VUB131
or antenna VUB086 + extension with support VUB105/VUB125/VUB131
Installation in plastic cabinet
ORRA and ORRS : antenna VUB084 or antenna VUB086
ORRD : antenna VUB084 + 90° BNC bend VUB060
Installation in metal cabinet
Antenna VUB084 + extension 0,5m VUB170
or antenna VUB086 + extension 0,5m VUB170
