FMS-2000C
LIT-12013508
12
Item Component
1 FMS-2000C Critical Environment Controller display
2 Display bracket
3 Wall
4 Stud
5 Rough-in box
6 Mounting screw
7 Set screw
Table 2: FMS-2000C Critical Environment Controller components for a new application
Figure 7: FMS-2000C Critical Environment Controller display side view of a new application
