FMS-2000C
LIT-12013508
41
Congurations and settings
Mode S1 - 1 S1 - 2 S1 - 3 S1 - 4 S1 - 5 S1 - 6 S1 - 7 S1 - 8
AI-1 5 VDC OFF OFF
AI-1 20 mA ON OFF
AI-1 10 VDC OFF ON
Not valid ON ON
AI-2 5 VDC OFF OFF
AI-2 20 mA ON OFF
AI-2 10 VDC OFF ON
Not valid ON ON
AI-3 5 VDC OFF OFF
AI-3 20 mA ON OFF
AI-3 10 VDC OFF ON
Not valid ON ON
AI-4 5 VDC OFF OFF
AI-4 20 mA ON OFF
AI-4 10 VDC OFF ON
Not valid ON ON
Protocol Selection S3 position 7 S3 position 8
Reserved OFF OFF
Metasys N2 ON OFF
BACnet MS/TP default ON ON
AO-1 voltage range selection OFF = 0 VDC - 10 VDC ON = 0 VDC - 5 VDC
AO-2 voltage range selection OFF = 0 VDC - 10 VDC ON = 0 VDC - 5 VDC
AO-3 voltage range selection OFF = 0 VDC - 10 VDC ON = 0 VDC - 5 VDC
AO-4 voltage range selection OFF = 0 VDC - 10 VDC ON = 0 VDC - 5 VDC
Direction Description
Left Digital inputs pulled high triggered by active low input is default
Right Digital inputs pulled low triggered by active high input, up to 24 VDC
Table 24: Analog input conguration settings S1
Table 25: Protocol selection settings
Table 26: Controller conguration DIP switch S4
Table 27: Controller conguration slide switch S5
