FMS-2000C
LIT-12013508
38
Wiring communications to BACnet MS/TP
Number Component
1 DIP switch
2 Controller
3 Supervisory device
4 FMS-2000C Critical Environment Controller
Figure 32: BACnet MS/TP wiring diagram
Table 18: BACnet MS/TP wiring components
+
24V_IN
–
+
DSPLY
RS485
–
+
BACnet
MS/TP
–
REF
