Johnson Controls FMS-2000C Installation Guide

FMS-2000C
LIT-12013508
45
Metasys N2 objects
See Table 34 to Table 39 for a list of points available for integration in a BMS. They contain the objects for open N2 integration.
Object instance Analog inputs Read or write
AI-1 Analog input 1, default: primary pressure Read only
AI-17 Analog input 2 Read only
AI-18 Analog input 3 Read only
AI-19 Analog input 4 Read only
AI-20 Thermistor input 1 Read only
AI-21 Thermistor input 2 Read only
Object instance Analog outputs Read or write
AO-1 Analog output 1, default: primary damper control Read only
AO-11 Analog output 2, default: supply or exhaust damper control Read only
AO-12 Analog output 3, spare control output Read only
AO-13 Analog input 4, spare control output Read only
Object instance Binary inputs Read or write
BI-3 Digital input 1, default: primary room switch Read only
BI-4 Digital input 2, default: secondary room switch Read only
BI-5 Digital input 3, spare digital input Read only
BI-6 Digital input 4, spare digital input Read only
Object instance Binary outputs Read or write
BO-1 Relay output 1, default: primary alarm relay output Read only
BO-2 Relay output 2, spare relay output Read only
BO-3 Relay output 3, spare relay output Read only
BO-4 Relay output 4, spare relay output Read only
Table 34: Analog inputs for integration in a BMS
Object instance Internal oat values Read or write
ADF-1 PID Control loop 1 setpoint, primary pressure Read or write
ADF-2 Primary room alarm relay high setpoint Read or write
ADF-3 Primary room alarm relay low setpoint Read or write
ADF-4 Secondary room alarm relay high setpoint Read or write
ADF-5 Secondary alarm relay low setpoint Read or write
ADF-8 Primary room low alarm setpoint Read or write
ADF-9 Primary room low warning setpoint Read or write
ADF-10 Primary room high warning setpoint Read or write
ADF-11 Primary room high alarm setpoint Read or write
ADF-13 PID control loop 2 setpoint Read or write
ADF-14 PID control loop 3 setpoint Read or write
Table 35: Analog outputs for integration in a BMS
Table 36: Binary inputs for integration in a BMS
Table 37: Binary outputs for integration in a BMS
Table 38: Internal oat values for integration in a BMS
